Shibang Storage Rack
1 / 5
| The New Light Duty Racking | ||||
|---|---|---|---|---|
| loading capacity(kg) | Shelf thickness | Upright thickness | Beam thickness | |
| 120kg/layer | 0.32mm thick cold rolled steel sheet | 30*50*0.7mm C steel | 30*50*0.6mm P steel | |
| The New Medium Duty Racking | ||||
| loading capacity(kg) | Shelf thickness | Upright thickness | Beam thickness | |
| 120kg/layer | 0.32mm thick cold rolled steel sheet | 30*50*0.7mm C steel | 30*50*0.6mm P steel | |
| Size(cm) | Body-frame weight(kg) | Sub-frame weight(kg) | loading capacity(kg) | |
|---|---|---|---|---|
| Thicken 200*60*200=4 layers | 44±0.5 | 40±0.5 | 180kg/layer | |
| Thicken 200*50*200=4 layers | 41±0.5 | 37±0.5 | 180kg/layer | |
| Thicken 200*40*200=4 layers | 39±0.5 | 35±0.5 | 180kg/layer | |
| Thicken 180*60*200=4 layers | 41±0.5 | 37±0.5 | 180kg/layer | |
| Thicken 150*60*200=4 layers | 37±0.5 | 32±0.5 | 180kg/layer | |
| Thicken 150*50*200=4 layers | 33±0.5 | 28±0.5 | 180kg/layer | |
| Thicken 150*40*200=4 layers | 30±0.5 | 26±0.5 | 180kg/layer | |
| Thicken 120*60*200=4 layers | 30±0.5 | 26±0.5 | 180kg/layer | |
| Thicken 120*50*200=4 layers | 27±0.5 | 23±0.5 | 180kg/layer | |
| Thicken 120*40*200=4 layers | 25±0.5 | 21±0.5 | 180kg/layer | |
| Thicken 100*50*200=4 layers | 25±0.5 | 21±0.5 | 180kg/layer | |
| Thicken 100*40*200=4 layers | 23±0.5 | 19±0.5 | 180kg/layer | |
| The New 200*50*200=4 layers | 33±0.5 | 29±0.5 | 120kg/layer | |
| The New 150*50*200=4 layers | 27±0.5 | 23±0.5 | 120kg/layer | |
| The New 150*40*200=4 layers | 25±0.5 | 21±0.5 | 120kg/layer | |
| The New 120*50*200=4 layers | 24±0.5 | 20±0.5 | 120kg/layer | |
| The New 120*40*200=4 layers | 21±0.5 | 18±0.5 | 120kg/layer | |
| The New Medium 200*60*200=4 layers | 49±0.5 | 42±0.5 | 240kg/layer | |
| The New Medium 200*50*200=4 layers | 44±0.5 | 38±0.5 | 240kg/layer | |
| The New Medium 150*60*200=4 layers | 41±0.5 | 34±0.5 | 240kg/layer | |
| The New Medium 150*50*200=4 layers | 37±0.5 | 30±0.5 | 240kg/layer | |
| Item | Value |
|---|---|
| Material | Steel |
| Feature | Corrosion Protection |
| Type | Boltless / Rivet Shelving, Selective Pallet Rack |
| Length of Layers | L1200/1500 |
| Layer | 5 Layer, 1 Layer, 2 layer, 3 layer, 4 layer, 8 Layers |
| Surface Treatment | powder coated |
| Installation | Industrial Shelving |
| Model Number | LSR001 |
| Special Feature | Adjustable |
We start from 2008, and sell to the Domestic Market (88.00%), Western Europe (5.00%), Central America (3.00%), South America (2.00%), Eastern Asia (1.00%), and Africa (1.00%). There are a total of about 301-500 people in our office.
Always a pre-production sample before mass production; Always final Inspection before shipment.
Warehouse Storage Rack, Pallet Rack, Cantilever Racking, Supermarket Rack, Household Shelf.
25 years of design and development experience. With our creative ideas and professional designs, we can make and design all shelves according to our clients' requirements.
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES;
Accepted Payment Currency: USD, CNY;
Accepted Payment Type: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow;
Language Spoken: English, Chinese.
