Shibang Storage Rack
1 / 5
| Size | Layers | Load Capacity | Color | Materials Specifications | Price (USD/Set) |
|---|---|---|---|---|---|
| Light Duty Specifications (120KG/Layer Capacity) | |||||
| L100*D40*H200 | 3 Layers 4 Layers 5 Layers Custom |
120Kg / Layer | Blue, White, Grey, Frosted Black, Custom | Column: 30*50*0.5 C steel Beam: 30*50*0.45 P steel Laminate: 0.3mm (0.23 bar) |
45 to 55 |
| L100*D50*H200 | 45 to 55 | ||||
| L120*D40*H200 | 47 to 57 | ||||
| L120*D50*H200 | 50 to 60 | ||||
| L150*D40*H200 | 52 to 62 | ||||
| L150*D50*H200 | 55 to 65 | ||||
| L180*D40*H200 | 58 to 68 | ||||
| L180*D50*H200 | 66 to 76 | ||||
| Reinforced Specifications (180KG/Layer Capacity) | |||||
| L100*D40*H200 to L200*D60*H200 |
3 Layers 4 Layers 5 Layers Custom |
180Kg / Layer | Blue, White, Grey, Frosted Black, Custom | Column: 30*50*0.7 C steel Beam: 30*50*0.6 P steel Laminate: 0.4mm (0.3 bar) |
Contact for Price |
| Size | Layers | Load Capacity | Materials Specifications | Color |
|---|---|---|---|---|
| Medium Duty Specifications (200KG/Layer Capacity) | ||||
| L150*D50*H200 L150*D60*H200 L200*D50*H200 L200*D60*H200 |
3 Layers 4 Layers 5 Layers |
200Kg / Layer | Column: 40*80*0.5 C steel Beam: 40*60*0.45 P steel Laminate: 0.3mm (0.3 bar) |
Blue, White, Grey, Frosted Black, Custom |
| Heavy Medium Duty Specifications (240KG/Layer Capacity) | ||||
| L120*D50*H200 L120*D60*H200 L150*D50*H200 L150*D60*H200 L200*D50*H200 L200*D60*H200 |
3 Layers 4 Layers 5 Layers |
240Kg / Layer | Column: 40*80*0.7 C steel Beam: 40*60*0.65 P steel Laminate: 0.35mm (0.3 bar) |
Blue, White, Grey, Frosted Black, Custom |
| Size (cm) / Specification | Body-frame Weight (kg) | Sub-frame Weight (kg) | Loading Capacity |
|---|---|---|---|
| Thicken 200*60*200 (4 layers) | 44 ± 0.5 | 40 ± 0.5 | 180kg/layer |
| Thicken 200*50*200 (4 layers) | 41 ± 0.5 | 37 ± 0.5 | 180kg/layer |
| Thicken 200*40*200 (4 layers) | 39 ± 0.5 | 35 ± 0.5 | 180kg/layer |
| Thicken 180*60*200 (4 layers) | 41 ± 0.5 | 37 ± 0.5 | 180kg/layer |
| Thicken 150*60*200 (4 layers) | 37 ± 0.5 | 32 ± 0.5 | 180kg/layer |
| Thicken 150*50*200 (4 layers) | 33 ± 0.5 | 28 ± 0.5 | 180kg/layer |
| Thicken 150*40*200 (4 layers) | 30 ± 0.5 | 26 ± 0.5 | 180kg/layer |
| Thicken 120*60*200 (4 layers) | 30 ± 0.5 | 26 ± 0.5 | 180kg/layer |
| Thicken 120*50*200 (4 layers) | 27 ± 0.5 | 23 ± 0.5 | 180kg/layer |
| Thicken 120*40*200 (4 layers) | 25 ± 0.5 | 21 ± 0.5 | 180kg/layer |
| Thicken 100*50*200 (4 layers) | 25 ± 0.5 | 21 ± 0.5 | 180kg/layer |
| Thicken 100*40*200 (4 layers) | 23 ± 0.5 | 19 ± 0.5 | 180kg/layer |
| The New 200*50*200 (4 layers) | 33 ± 0.5 | 29 ± 0.5 | 120kg/layer |
| The New 150*50*200 (4 layers) | 27 ± 0.5 | 23 ± 0.5 | 120kg/layer |
| The New 150*40*200 (4 layers) | 25 ± 0.5 | 21 ± 0.5 | 120kg/layer |
| The New 120*50*200 (4 layers) | 24 ± 0.5 | 20 ± 0.5 | 120kg/layer |
| The New 120*40*200 (4 layers) | 21 ± 0.5 | 18 ± 0.5 | 120kg/layer |
| The New Medium 200*60*200 (4 layers) | 49 ± 0.5 | 42 ± 0.5 | 240kg/layer |
| The New Medium 200*50*200 (4 layers) | 44 ± 0.5 | 38 ± 0.5 | 240kg/layer |
| The New Medium 150*60*200 (4 layers) | 41 ± 0.5 | 34 ± 0.5 | 240kg/layer |
| The New Medium 150*50*200 (4 layers) | 37 ± 0.5 | 30 ± 0.5 | 240kg/layer |
