| Light Duty Racking - Standard Series (120 Kg / Layer Capacity) | ||||
|---|---|---|---|---|
| Size (Length * Depth * Height) | Number of Layers | Loading Capacity | Color Options | Materials & Dimensions |
| L100 * D40 * H200 cm | 3 Layers / 4 Layers / 5 Layers / Custom |
120 Kg / Layer | Blue, White, Grey, Frosted Black, Custom | Column: 30 * 50 * 0.5mm C-Steel Beam: 30 * 50 * 0.45mm P-Steel Laminate: 0.3mm (with 0.23 bar support) |
| L100 * D50 * H200 cm | ||||
| L120 * D40 * H200 cm | ||||
| L120 * D50 * H200 cm | ||||
| L150 * D40 * H200 cm | ||||
| L150 * D50 * H200 cm | ||||
| L180 * D40 * H200 cm | ||||
| L180 * D50 * H200 cm | ||||
| Light Duty Racking - Reinforced Series (180 Kg / Layer Capacity) | ||||
|---|---|---|---|---|
| Size (Length * Depth * Height) | Number of Layers | Loading Capacity | Color Options | Materials & Dimensions |
| L100 * D40 * H200 cm | 3 Layers / 4 Layers / 5 Layers / Custom |
180 Kg / Layer | Blue, White, Grey, Frosted Black, Custom | Column: 30 * 50 * 0.7mm C-Steel Beam: 30 * 50 * 0.6mm P-Steel Laminate: 0.4mm (with 0.3 bar support) |
| L100 * D50 * H200 cm | ||||
| L120 * D40 * H200 cm | ||||
| L120 * D50 * H200 cm | ||||
| L120 * D60 * H200 cm | ||||
| L150 * D40 * H200 cm | ||||
| L150 * D50 * H200 cm | ||||
| L150 * D60 * H200 cm | ||||
| L180 * D60 * H200 cm | ||||
| L200 * D40 * H200 cm | ||||
| L200 * D50 * H200 cm | ||||
| L200 * D60 * H200 cm | ||||
| Heavy-Light Racking Series (200 Kg / 240 Kg Capacity) | ||||
|---|---|---|---|---|
| Size (Length * Depth * Height) | Number of Layers | Loading Capacity | Color Options | Materials & Dimensions |
| L150 * D50 * H200 cm | 3 Layers / 4 Layers / 5 Layers | 200 Kg / Layer | Blue, White, Grey, Frosted Black, Custom | Column: 40 * 80 * 0.5mm C-Steel Beam: 40 * 60 * 0.45mm P-Steel Laminate: 0.3mm (with 0.3 bar support) |
| L150 * D60 * H200 cm | ||||
| L200 * D50 * H200 cm | ||||
| L200 * D60 * H200 cm | ||||
| L120 * D50 * H200 cm | 3 Layers / 4 Layers / 5 Layers | 240 Kg / Layer | Blue, White, Grey, Frosted Black, Custom | Column: 40 * 80 * 0.7mm C-Steel Beam: 40 * 60 * 0.65mm P-Steel Laminate: 0.35mm (with 0.3 bar support) |
| L120 * D60 * H200 cm | ||||
| L150 * D50 * H200 cm | ||||
| L150 * D60 * H200 cm | ||||
| L200 * D50 * H200 cm | ||||
| L200 * D60 * H200 cm | ||||
| Thicken Light Duty Racking Frame Weights (4 Layers, 180kg/layer capacity) | |||
|---|---|---|---|
| Size (cm) | Body-frame Weight (kg) | Sub-frame Weight (kg) | Loading Capacity |
| Thicken 150 * 50 * 200 = 4 layers | 33 ± 0.5 | 28 ± 0.5 | 180 Kg / Layer |
| Thicken 150 * 60 * 200 = 4 layers | 37 ± 0.5 | 32 ± 0.5 | 180 Kg / Layer |
| Thicken 200 * 50 * 200 = 4 layers | 41 ± 0.5 | 37 ± 0.5 | 180 Kg / Layer |
| Thicken 200 * 60 * 200 = 4 layers | 44 ± 0.5 | 40 ± 0.5 | 180 Kg / Layer |
| Medium Duty Racking Spec Sheet | |||
|---|---|---|---|
| Product name | Medium Duty Racking | Loading capacity | 300 Kg / Layer |
| Shelf thickness | 0.5mm thick cold rolled steel sheet | Color | White |
| Upright thickness | 40 * 80 * 1.0mm C-Steel | Material | Cold rolled steel |
| Beam thickness | 40 * 60 * 1.0mm P-Steel | ||
| Thicken Medium Duty Racking Frame Weights (4 Layers, 300kg/layer capacity) | |||
|---|---|---|---|
| Size (cm) | Body-frame Weight (kg) | Sub-frame Weight (kg) | Loading Capacity |
| Thicken 150 * 50 * 200 = 4 layers | 41 ± 0.5 | 35 ± 0.5 | 300 Kg / Layer |
| Thicken 150 * 60 * 200 = 4 layers | 45 ± 0.5 | 38 ± 0.5 | 300 Kg / Layer |
| Thicken 200 * 50 * 200 = 4 layers | 50 ± 0.5 | 43 ± 0.5 | 300 Kg / Layer |
| Thicken 200 * 60 * 200 = 4 layers | 55 ± 0.5 | 48 ± 0.5 | 300 Kg / Layer |
Quality is guaranteed through strict manufacturing processes. We always provide a pre-production sample for confirmation before launching mass production, and a final inspection is always conducted before shipment.
We offer a comprehensive selection of shelving and storage solutions, including Warehouse Storage Racks, Pallet Racks, Cantilever Racking, Supermarket Racks, and Household Shelves.
We carry 25 years of design and development experience. Leveraging our creative concepts and highly professional engineering, we can design and manufacture customized shelves that align perfectly with our clients' specific layout and budget needs.
We support a wide array of terms including FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, DAF, DES, and Express Delivery. Supported payment currencies include USD and CNY, which can be paid via T/T, L/C, D/P, D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, or Escrow.
Yes, custom requests are fully welcomed. Standard sizes range from 100cm to 200cm in width, but we can customize layer numbers (3, 4, 5, or more), colors (Blue, White, Grey, Frosted Black), and specify steel dimensions to meet custom requirements.
Our structures utilize heavy-grade cold-rolled steel, including high-durability C-Steel for columns and P-Steel for beams. They are coated with an environmental protection spray providing corrosion protection and long-term durability.
